Hyland Deadbolt
Keyed Deadbolt Lock Set
Model
Reference available on request
A single cylinder keyed deadbolt with hardened bolt, supplied with strike plate and fixings.
- Material
- Stainless steel / zinc alloy
- Door type
- Timber · Steel
Find Keyed Deadbolt Lock Set on our Alibaba storefront
Opens our storefront already searched for this model — trade assurance, tiered pricing and order tracking are handled there.
Technical specifications
- Deadbolt throw
- 25mm, zinc die-cast with hardened steel roller insert
- Cylinder
- 5-pin tumbler, solid brass plug, two nickel-plated brass keys
- Chassis
- Zinc plated steel internal components
- Trim
- Stainless steel, brass or steel
- Handing
- Fully reversible, left or right hand
- Feature
- Free-turning cylinder trim prevents wrenching; cylinder removable for rekeying
- Keying
- Can be keyed to pair with an entrance bored lock
Configuration
- Material
- Stainless steel / zinc alloy
- Available finishes
- Satin Stainless · Polished Brass
- Suitable door types
- Timber · Steel
Standards and certifications
ISO 9001
ISO 9001:2015
Certification scope must be checked against the named model before specification.
Downloads
Datasheets, CAD files and installation instructions are available on request while the verified download library is being prepared.
